Properties & Features
S-Link™ is a CAN-based control system used for communication between Sleipner products installed on a vessel.
- Compact and waterproof plugs
- Keyed and color-coded connectors to ensure correct and easy installation
- Different cable lengths, extenders and T-connectors makes the system scalable and flexible to install
A PRO™ thruster system enables you to apply only the necessary power to complete your maneuver. The variable speed control eliminates the noise associated with standard on/off thrusters.
The system also includes a practical hold-function. In a dual system (bow and stern) a single press of a button will keep you alongside the docks – making docking truly a one-person job.
Speed controlled thrusters are the best choice for joystick interaction.
- Docking your vessel has never been easier. With a single press of a button, you can rely on your thrusters to maintain the boat controlled against the dock while stepping off to secure the lines — making docking truly a one-person job.
- Sleipner control panels are programmed to shut down automatically after inactivity to prevent accidental activation.
- This product comes with a safety stop button to quickly shut down the system with a single button press.
- This product is manufactured for installations in environments that may experience moist or occasional splashes.
- This product is constructed from UV-resistant material providing additional protection from the damaging effects of ultraviolet sunlight.
Specifications
| Main power | Value |
|---|---|
| Power supply | 12V DC, 24V DC |
| Protection standards | Value |
|---|---|
| Ingress protection | IPx6 (front), IPx4 (back) |
| Alarms | Value |
|---|---|
| Alarm notification | Audio, Visual |
| Internal alarm buzzer sound level (dB) | Yes |
| System builder connections | Value |
|---|---|
| Designed to operate Sleipner: | Hydraulic Systems |
| Programmed for Sleipner: | Proportional systems |
| Operates | 2x Thrusters |
| Operate Systems | Thruster Systems |
| Features | Value |
|---|---|
| PRO – Variable Speed Control | Yes |
| S-Link | Yes |
| UV Protection | Yes |
| Splash-Proof | Yes |
| Quick Stop | Yes |
| Smart Shut-Off | Yes |
| Hold Thrust | Yes |
| Dimensions | Value |
|---|---|
| (H) Height | 141mm / 5.55in |
| (W) Width | 83mm / 3.3in |
| (a) | 65.66mm / 2.6in |
| (b) | 31.8mm / 1.25in |
| Material | Value |
|---|---|
| Product colour finish | Black |
| Control panel design | Value |
|---|---|
| Control panel type | Hold-button, Spring |
| Screen type | Integrated |
| Ideal vessel integration | Value |
|---|---|
| Typical vessel class | Motor boat, Sail boat |
