The Only Vessel Attitude Control System
Seakeeper Ride eliminates up to 70% of underway pitch and roll providing comfort, control, and confidence.
Need For Speed
SEAKEEPER RIDE | ZIPWAKE SERIES S | ZIPWAKE SERIES E | LENCO PRO CONTROL AUTO | HUMPHREE H SERIES | SEAKEEPER RIDE ADVANTAGE | |
Deployment Speed | 0.1 sec. | 1.5 sec. | 1.6 sec. | 3.2 sec. | .7 sec. | Fastest deployment to eliminate motions before they’re felt |
Blade Stroke |
1 in. |
1.2 in. |
2.4 in. |
2.25 in. |
1.97 in. | Greater performance with a shorter stroke, maximizing lift to drag ratio |
Blade Rate | 10 in/s | 0.8 in/s | 1.5 in/s | 0.7 in/s | 2.8 in./s | Fastest speed |
System Components
Port & 1 Starboard Controller
Seakeeper Ride controllers are installed on the transom on either side of the engine(s)
Software Module
The “brain” of the system that includes Seakeeper’s proprietary software and motion sensors
Distribution Module
Provides power and communication between the controllers and the software module
User Interface
Manually adjusting trim and list from a keypad is so last year. Seakeeper Ride is completely automatic with no manual keypad adjustments needed. Just turn the key and enjoy the ride. Our interface is compatible with select models including Garmin, Raymarine, Simrad, Navico, Lowrance, B&G, Furuno and Q Experience.
Performance
SEAKEEPER RIDE COMPONENTS
- Software Module – the “brains” of the system
- Seakeeper Ride Proprietary CAN Bus – Communication distributer.
- Distribution Module (2) – connection hubs for power and communication distribution
- Controllers (4) – the physical system that moves in and out of the water to eliminate motions
- Seakeeper Ride App (installed on MFD) – compatible with select Garmin, Raymarine, Simrad, Navico, Lowrance, B&G, Furuno, and Q Experience models
- Keypad (optional) – for manual adjustments
BOAT’S OWN SUPPLY
- 25 Amp circuit breaker controllers or fuse
- Positive and negative ground terminals
- Positive and negative power terminals
- NMEA 2000 backbone
Additional Features
Rapid Actuation
Rotary blades deploy at a rate of up to 300 mm per second, making 100 adjustments every second; enabled by power-dense rotary design that requires just 7-10 Amps for operation.
Intuitive
Predicts motion and responds instantaneously to eliminate them before they’re felt with no buttons to push nor adjustments to make, providing a boating experience you never imagined.
Full Underway Control
Controls all motions (pitch, roll, yaw) thanks to deployment speed and proprietary control software and hardware.
Reliable
Drivetrain is completely sealed in a dry and greased environment with no mechanical exposure to saltwater.
Simple Installation
Easily installed on most transoms, both in new and aftermarket boats.
