The award winning Muir Storm VR/C600 12V/24V 600W Anchor Winch with luxury stainless steel finish revolutionises rope chain windlass technology are the preferred choice for high performance and smooth operation.
The Muir Storm VR600 12V or 24V 600W Anchor Winch of vertical windlasses provides the strength of conventional vertical windlasses but with advanced and innovative concepts.
Muir Storm VR600 12V/24V 600W Anchor Winch provide the highest level of security and safety.
Muir Storm VR/C600 12V/24V 600W Anchor Winch
Options
- Extra deck clearance kit for up to 150mm/6” deck thickness
- Full range of accessories including chain and rope available
- Electrical operating options & accessories
Auto anchor – chain counter
| Model | VR600 |
|---|---|
| Vessel Length | 5-9m |
| Power Supply (DC) | 12V/24V |
| Motor (Watts) | 600 |
| Max Load | 300kg (660lb) |
| Work Load | 100kg (220lb) |
| Amps Work Load | 75/40 |
| Max Line Speed | 25m/min (80ft/min) |
| Chain Size | 6mm (1/4″) |
| Rope Size | 12mm (1/2″) |
| Net Weight | DC 12kg (DC 26lb) |
Muir Storm VR/C600 12V/24V 600W Anchor Winch
Features
- Rope chain combination gypsy
- Rope Chain Management System (RCMS)
- Gypsy with low profile clutch top arrangement (VR)
- Heavy duty marine grade, dual direction motor in 12V DC
- 316 Stainless steel
- Quick fit adaptor
- Stainless steel shaft
- Cone clutch/brake
- Stainless steel mounting studs
- Shaft seal
- Self lubricating bush
- Clutch release handle
- Installation/Operation booklet
Options
- Extra deck clearance kit for decks up to 150mm/6”
- Full range of accessories including chain, rope,
chain stoppers, snubber kits and devil claws - Electrical operating options and accessories
- Auto anchor – chain counter
Standard package contains
- Circuit breaker & mounting panel
- Helm control rocker switch & mounting panel
- 12-24v reversing solenoid kit to suit all application
- Deck mounting studs & fasteners
- Clutch release handle
- Installation/Operation booklet
Technical Specifications Download
Download the PDF Technical Specification Document for the Vertical Windlass Muir Storm VR / VRC 600
